System description
Lis
t representation and list types
9
171 |
184
Building Technologies
A6V10211076_i_en_
--
Fire Safety
2015
-
12
-
15
9.9 List representation and list types
By the list representation and the possibility to search in lists, a large number of list
entries and list positions can be indicated on the display.
There are the following types of lists:
● Event lists
● Element lists
● Selection lists
9.9.1 Event lists
Event lists include events that have occurred in the fire detection installations and
belong to different categories.
In the 'Message summary' main menu item messages are combined in event
categories. These event categories may be opened as an event list.
In the '
Message summary
' main menu item only those event categories are
indicated in which events have actually occurred.
In accordance with the event categories, there are the following event lists:
● 'ALARM'
● 'Pre-ALARM'
● 'Fault'
● 'Isolation'
● Test
● ↑ 'Technical message'
● 'Activation'
● 'Information'
All events are also included in the event list in the '
Event memory
'. T
his '
Event
memory' list has a different layout as well as additional functions. For this reason,
a separate chapter 'Event memory' is included.
The figure below shows an example of an 'Isolation' event list.
Waiting for confirmation RT
002 Isolations
Autom.
Sounder 2
Zone OFF
001
OFF
002
Execute
Commands
Show
Intervention text
More
Options
See also
1 Event memory [➙ 169]
