Siemens FT724 User Manual

Setup of the Person Machine Interface
PMI
3
20 | 184
Building Technologies
A6V10211076_i_en_
--
Fire Safety
2015
-
12
-
15
6 Key switch (optional) ● An access level can be enabled with the key switch.
● The accessible access level is configurable.
● The key switch has two positions: On (horizontal position), Off
(vertical position)
7 <Alarm device> button
● Deactivates the ↑ alarm devices in the event of alarm (password
required)
8 System fault LED (yellow) ● Lights up yellow when a fault is present
9 Operation LED (green) ● Lights up green during operation
A <More alarms> button ● Pressing <More alarms> opens the 'ALARMS' event list.
● If the 'ALARMS' event list is already open, <More alarms> assumes
the function of the button <▼>, changing to the next alarm event
upon activation.
S Softkeys 1–3
● Softkeys are buttons by means of which functions may be carried
out that are displayed in the three fields of the softkey line on the
display.
● These three black fields contain the names of the functions in white
font.
● The functions of the softkeys may change depending on the situation
and the contents of the display.
● Always the most important functions are assigned to the softkeys 1
and 2.
X
<Silence buzzer>,
<Acknowledge>, <Reset>,
<Alarm delay off>, <Premises
manned> standard buttons
● <Silence buzzer> switches the buzzer off.
● <Acknowledge> acknowledges all events that can be acknowledged.
Confirms presence (↑ AVC, IC). Switches off the buzzer and internal
sounders.
● <Reset> resets all events that can be reset (password required).
● <Alarm delay off> switches off the alarm delay for all events. In the
event of an alarm, the remote transmission or global alarming is
activated immediately.
● <Premises manned> switches between 'Manned' and 'Unmanned'
operation modes (password required). Opens the event list in the
case of a "mixed" condition (↑ visibility on several ↑ areas with
different 'Manned' and 'Unmanned' settings).
k1 Configurable keys with LEDs
● These two keys may, for example, be configured with the following
functions: 'VdS counter' or 'Switch off detector zone' display.
k2 Configurable LEDs ● Freely configurable for the indication of events or conditions
Inscription strips may be inserted to label the PMI.
You will find a template for this in document A6V10217440. See chapter
'Applicable documents'.
