Siemens SIMATIC PCS7 User Manual

5-3
Batch flexible , Manual
C79000-G7076-C650-02
5.1 Tasks of batch control
The batch control application is a program package which forms part of the
basic system – in other words, it is an indispensible requirement for using
BATCH flexible. Batch control is responsible for executing the batches and
for visualizing and operating the batches in the OS.
Batch
control
BATCH flexible
Object
Manager
(BOM)
Control
Recipe
Generator
Batch
Data
Pre -
paration
Batch
planning
Recipe
Editor
BATCH Broker
Figure 5-1 Batch control as a BA TCH flexible application
With the aid of batch control you can display the execution of a control
recipe. Here the representation of the control recipe is the same as that of the
recipe editor but with a few changes on the menu and tool bars.
For executing the control recipe of a batch, batch control writes the setpoint
parameters of automation functions in their interface blocks of the PLC,
starts the corresponding processing blocks, and waits for their end signals.
What does batch
control do?
The batch control
sequence
Batch control
