3-17
Batch
flexible
, Manual
C79000-G7076-C650-02
The occupancy markers (read or write) of the recipe you selected can be set
or cleared (this also applies to all other BATCH objects) provided you have
the corresponding user privileges (see Page 3-31). This thus provides
protection against different applications and systems simultaneously
influencing the same recipe.
Under normal circumstances the occupancy markers (read / write) are
automatically set or cleared by the applications (for example, recipe editor).
If only the ’read’ occupancy marker has been set, any number of other users
or applications can read the recipe. If however the ’write’ occupancy marker
has been set, then the recipe cannot be opened by another user or application,
nor can it be read. Only the object properties of the recipe can always be
read.
In exceptional cases (for example, in the event of an error) the user can
cancel occupancy of a recipe (providing he has the corresponding user
privileges).
Table
3-3
Occupancy marking of all BA
TCH objects
Occupied by another
li ti
Can be occupied
py
application
For reading For writing
Not occupied Yes Yes
Occupied for reading Yes No
Occupied for writing No No
This function is not dependent on object type – in other words, an import file
may contain batches or recipes. Via a window in which you type both path
and file name, you can activate the import process with the command ’Open’
(for an example of the window see Page 3-38). When you then click on
’Close’ a check is made whether importation is permitted before it is carried
out. This check looks to see whether an identical data record already exists as
a recipe. If this is the case, importation will be refused.
Once importation is completed the contents of the imported file will be
displayed along with the recipe name, the version identifier and so on.
Recipes released for testing will be given the status ’incomplete’ while
recipes released for production will be given the status ’release canceled’.
A selected recipe is exported as an ASCII file. In the next menu you should
specify the path and export file name. The file type is .bfx.
Occupy and cancel
occupation
Importing
Exporting
BATCH flexible Object Manager
