1.4 System overview
BATCH flexible is composed of the following software packages:
– Recipe System (RS)
– Batch Control (BC)
– Batch Planning (BP)
– Batch Data Management (BDM)
To be able to use BATCH flexible a PC must have a certain minimum
configuration, the basic system. Other expansion configurations and possible
combinations are shown in the following diagram:
RS
BC
= basic system
(min. 1* per system)
BDM
= max. 1* per system
RS BC BP
= x times = y times = z times
BB : BATCH Broker
RS : Recipe System
BC : Batch Control
BDM : Batch Data Management (option)
BP : Batch Planning (option)
BB
with a multiple disk system
must be installed on every
PC
Figure 1-4 System overview of the BA TCH flexible software packages
How is BATCH
flexible made up?
System overview
