Here the record of a recipe which you have selected will be activated. In the
next menu you can set record options for the scope of the record and for
printing. Individual recipes can be written as a record, either in their entirety
or in part. Example of a recipe record:
Start
End
FKAB_3
HZFK_3 ABR_3 VENT_7
PUMP_3
ABFK_3
TROK_1
1
2
3
4
5
6
1
23
5
6
7
BATCH flexible
Recipe record
16.10.96 12:19:42
Recipe: Dyeing_unit_R V ersion: V001
Status: Released for production
Product: Max. and Sirius finish dyeing Quality: Absorbent
Quantity:
Standard batch min. batch max. batch Unit
200 100 300 liter
Figure 3-9 Example of a recipe record (extract)
Print
BATCH flexible Object Manager
