A-10
Batch flexible , Manual
C79000-G7076-C650-02
A.2.4 BATCH–specific additions to the standard function blocks
Table A-4 I/O bar with BA TCH-specific additions to the standard
function blocks
Parameter
name
Meaning used by Data type I/O
BATCH_EN Basic release for use
of processing block
by AF
– Values supplied by
interconnection or parametrizing
in the ES by the project planner
BOOL I
OCCUPIED BATCH reservation
identifier. The
processing block has
already been occupied
by an AF
– Logic of basic control (ES SFC)
writes
BOOL I
CH_NAME Batch designation – Values supplied by write access
of logic of basic control (ES SFC
or interlocking or
interconnection)
S16 I
STEP_NO
(input)
Step no. in the recipe – Values supplied by write access
of logic of basic control (ES SFC
or interlocking or
interconnection)
WORD I
CH_ID Serial number of the
batch; assigned
internally in the
BATCH system
– Values supplied by write access
of logic of basic control (ES SFC
or interlocking or
interconnection)
WORD I
