1.8 BATCH
flexible
session concept
Table 1-2 shows BATCH flexibles action-oriented sequence.
Table
1-2
BATCH
flexible
session concept
Procedure Application /page
reference
1. Basic automation configuration see Chapter 9:
Configure AF interface blocks, UNIT blocks, TRANSITION blocks,
AF processing blocks
ES/CFC
2. Install BATCH flexible system Setup, Page 2-4
3. Configure BATCH system BOM
Enter user, assign user authorization levels Page 3-30
4. Configure BATCH data BOM
Read in configuration data from ES and check Page 3-38
Add to plant data (product list, physical units, AF types, parameter types) Page 3-40
5. Create recipe Recipe editor
Create new recipe Page 4-17
Fill out recipe header mask with product / quality, standard formula,
lower and higher limits, engineering unit
Page 4-30
Create recipe topology (SFC):
Steps and transitions: sequential, parallel /alternative branches, loops
from Page 4-18
Assign automation functions to the steps and assign parameters Page 4-32
Specify step enabling conditions in the transitions Page 4-34
Check plausibility Page 4-36
Save recipe /save as Page 4-36
Release recipe ’for testing’ or ’for production’ Page 4-38
