5-21
Batch
flexible
, Manual
C79000-G7076-C650-02
The batch status denotes the state of a batch. In the batch status list the only
batches which can be activated for control are those which have the status
released. A charge is started either automatically from the waiting state once the
first apparatus(es) has or have become free, or manually by operator action.
Table
5-7
Status of the batches during execution
Batch status Meaning
Released Only batches with this status can be activated for
control.
Waiting The batch has started but since the required
apparatus is not free it goes into this state.
Running The batch is now being executed.
Paused The batch has been paused by operator
intervention.
Error At least one AF in the batch’s control recipe has
signaled a fault or batch control itself is in an
exceptional state.
Aborted The
b
atc
h h
a
s b
ee
n a
borte
d by o
perato
r i
ntervention.
Furthe
r p
rocessin
g i
s n
o l
onge
r p
ossible.
Finished The batch has been executed, batch data are still
being acquired.
Paused
Run-
ning
Start
Error
Pause
Aborted
Cancel
Released
AF error
Batch run-
ning OK
Waiting
Finished
and apparatus is free
Start,
but apparatus is not free
Apparatus becoming free
AF error
corrected
Resume
Cancel
Figure
5-8
Batch status transitions in batch control
Status displays of
the batches
Batch control
