BATCH flexible
Recipe record
16.10.96 12:19:42
Recipe: Dyeing_unit_R
Version: V001
Product: Max. and Sirius finish dyeing
Pr oducts / input materials / r esidual materials
By-product Quantity Unit Adaption Category Description
Hydrochloric acid 20 Liter linear Input material
Lactic acid 100 kg linear Input material
Equipment allocations
Apparatus occupied fr om to Unit Mode
Dyeing vat 3 0 0 min do not occupy
Dryer 1 0 0 min do not occupy
AF 1 Drying
AF 3 Pumping
AF 4 Heating dyeing vat
Designation LL V alue HL Unit Adaption
Designation LL V alue HL Unit Adaption
On /of f? On
Duration of pumping 5 15 30 min
T emperature dyeing vat 70 78 130
0
C
Level make-up tank 10 30 50 %
AF 5 Filling dyeing vat fr om feedstock tank
Designation LL V alue HL Unit Adaption
Level feedstock tank 0 3 90 %
Level make–up tank 0 30 90 %
Connect to ener gy? Y es
AF 2
Drain dyeing vat
Occupancy > 0 AND AND
T emperature >= 75 AND AND
T ransition 1
1st operand Operator 2nd operand Unit Gate1 Gate2
Figure 3-10 Recipe record (extract), continued
The print preview feature allows you to view a recipe record on the screen as
it would appear when printed.
The ’Set up page’ function allows you to check and if necessary modify the
path specified for the layout and structure data of the batches and recipes.
Print preview
Set up page
