8.2 Operator and system messages
Batch control informs the OS signaling system about all operator actions and
status changes during the running time of the batch. This makes it possible to
track the execution of a batch with the aid of BATCH messages in the OS
message window.
Message numbers are reserved in the OS signaling system for BATCH
flexible. If no messages have as yet been provided there, batch control will
look after this at startup. The OS_MELD_OFFSET system variable described
at the end of Chapter 3 must be taken into consideration in the message
numbers. The following messages are generated by BATCH flexible:
Table 8-1 Overview of BA TCH flexible messages
No. Type Event Auxiliary process values *
1 OM Batch started (manual)
2 OM ** Batch started (automatic)
3 OM ** Batch finished
4 OM Batch aborted
5 OM Batch paused
6 OM Batch resumed
7–19 Reserve
20 OM ** AF %2 error 2 = AF-ID
21 OM ** AF %2 error corrected 2 = AF-ID
22 OM ** AF %2 activated 2 = AF-ID
23 OM ** AF %2 running 2 = AF-ID
24 OM AF %2 done 2 = AF-ID
25 OM AF %2 aborted 2 = AF-ID
26 OM AF %2 paused 2 = AF-ID
27 OM AF %2 resumed 2 = AF-ID
28 OM AF %2 run marker set 2 = AF-ID
29 OM AF %2 run marker removed 2 = AF-ID
30 OM AF %2 acknowledge operator instruction 2 = AF-ID
31 OM AF %2 operator instruction acknowledged 2 = AF-ID
32 OM AF %2 added 2 = AF-ID new
33 OM AF %2 removed 2 = AF-ID old
34 OM AF %2 replaces AF %5 2 = AF-ID new,
5 = AF-ID old
BATCH messages
Range of numbers
for BATCH
messages
Messages
