3-42
Batch
flexible
, Manual
C79000-G7076-C650-02
Select the ’Configure’ menu and then ’Production data’. First of all you will
see a list of the products and materials:
Production data
Products/materials Units
Adaption
routines
Edit...
New...
Delete
HelpClose
Cotton
Salt
Hazelnut
puree
Cocoa butter
Skim milk powder
Max. and Sirius finish dyeing
Lactose
Noisette chocolate
Nylon dowels
Polyester peroxide
Figure 3-24
Production data
Once you have selected a product or material, you can make changes via the
Edit key or declare the material to be product, input material or residual
material, and assign a code number (for example, product number 276345) as
well as a description. The code number is written to the AF interface block.
To accept these changes you should now press the OK key. With the Delete
key you can eliminate the products or materials from the production data.
The New.. key allows you to add new products or materials. In addition, via
the Qualities index card a window with Standard, for example, is displayed.
You can modify entries and/or expand them with an additional quality entry.
After selecting Units (via the index card) you will see a list. Make a selection
and then click on the Edit key: you can now modify a unit and then confirm
this by pressing the OK key. The Delete and New.. functions are used
analogously to products and materials.
With the Adaption routines (for example, linear, quadratic, etc.) you can
change the adaption routines after first making a selection with the Edit key.
You can also add a comment. With the New.. key you can add new adaption
routines (which may include a comment). These must have been created
previously (see Chapter 9).
Production data
Products and
materials
Units
Adaption routines
BATCH flexible Object Manager
