1-8
Batch flexible , Manual
C79000-G7076-C650-02
1.4.1 Hardware configuration
A basic distinction is drawn between the possible hardware configurations in
a single-user system and multi-user systems.
When a single-user system of this kind is used the BATCH flexible
applications run in the OS PC. This PC may also hold the planning and
design components of the ES system.
PLC S7-400
ES / WinCC OS /
BATCH flexible
SINEC L2
PLC S7-400
Figure 1-6 Single-user system
Overview
Single-user system
System overview
