1-9
Batch flexible , Manual
C79000-G7076-C650-02
In the case of the multi-user system the BATCH flexible program packages
can be distributed as desired. The packages Recipe System, Batch Planning
and Batch Control can also be multiply installed. Batch control and batch
data management require the OS system. Recipe System und batch planning
require Windows95/NT only. The following diagram shows an example of a
configuration:
Computer A
for example with:
- ES
- Recipe System
- Batch Planning
Computer B
for example with:
- WinCC OS
- Batch Control
- Batch Data Management
SINEC L2 / MPI
PLC S7-400
PLC S7-400
Terminal bus
Figure 1-7 Multi-user system
Multi-user system
System overview
