1-18
Batch
flexible
, Manual
C79000-G7076-C650-02
1.6 BATCH
flexible interfaces
BATCH
flexible
BATCH flexible-
Object Manager
(BOM)
Recipe
editor
Batch
planning
Database
Batch
control
Batch
data
prep’n
PLC
ASCII
FILE
ES
O&M DM MESS PDA
ES : Engineering System
DM : Data manager
O&M : Operating and Monitoring
OS : Operating System
MESS : Event processing
PDA : Process Data Acquisition
BOM : BATCH flexible Object Manager
PLC : Automation System
Equipment data
OS
DB interface
Figure
1-9
OS/ES/PLC interfaces
System overview
