Siemens SIMOTION Function Manual

Configuring the Path Object
3.3 Creating a path object
TO Path Interpolation
Function Manual, 11/2010
85
You can also copy an existing path object to the clipboard and then insert it under
another name.
Figure 3-3 Inserting a path object
2. Enter a name and, if necessary, the author, version, and comments, and click OK to
confirm.
The new path object will be inserted under TECHNOLOGY.
