Siemens SIMOTION Function Manual

Sample Project for the Path Interpolation
4.8 Programming the path interpolation in MCC
TO Path Interpolation
Function Manual, 11/2010
115
4.8.3.5 Programming the C-D linear path
For the C-D linear path, add the travel linear path command to the While loop and make the
following settings:
Figure 4-26 Programming the C-D linear path
