Siemens SINAMICS G120C DP User Manual

Number Name
p0180 Number of Drive Data Sets (DDS) / DDS count
p0300[0...n] Motor type selection / Mot type sel
p0304[0...n] Rated motor voltage / Mot U_rated
p0305[0...n] Rated motor current / Mot I_rated
p0505 Selecting the system of units / Unit sys select
p0595 Technological unit selection / Tech unit select
p0730 BI: CU signal source for terminal DO 0 / CU S_src DO 0
p0731 BI: CU signal source for terminal DO 1 / CU S_src DO 1
p0732 BI: CU signal source for terminal DO 2 / CU S_src DO 2
p0806 BI: Inhibit master control / Inhibit PcCtrl
p0870 BI: Close main contactor / Close main cont
p0922 PROFIdrive PZD telegram selection / PZD telegr_sel
p1080[0...n] Minimum velocity / v_min
p1082[0...n] Maximum velocity / v_max
p1520[0...n] CO: Torque limit upper / M_max upper
p2000 Reference speed reference frequency / n_ref f_ref
p2001 Reference voltage / Reference voltage
p2002 Reference current / I_ref
p2003 Reference torque / M_ref
p2006 Reference temperature / Ref temp
p2030 Fieldbus interface protocol selection / Fieldbus protocol
p2038 PROFIdrive STW/ZSW interface mode / PD STW/ZSW IF mode
p2079 PROFIdrive PZD telegram selection extended / PZD telegr ext
p7763 KHP OEM exception list number of indices for p7764 / KHP OEM qty p7765
p7764[0...n] KHP OEM exception list / KHP OEM excep list
Protecting the converter settings
7.2Know-how protection
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 179

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
