Siemens SINAMICS G120C DP User Manual

Table 8-24 Response identi󹪝ers, converter → control
AK Description
0 No response
1 Transfer parameter value (word)
2 Transfer parameter value (double word)
3 Transfer descriptive element
1)
4 Transfer parameter value (󹪝eld, word)
2)
5 Transfer parameter value (󹪝eld, double word)
2)
6 Transfer number of 󹪝eld elements
7 Converter cannot process the request.
In the most signi󹪝cant word of the parameter channel, the converter sends an error number to
the control, refer to the following table.
8 No master controller status / no authorization to change parameters of the parameter channel
interface
1)
The required element of the parameter is speci󹪝ed in IND (2nd word).
2)
The required element of the indexed parameter is speci󹪝ed in IND (2nd word).
Table 8-25 Error numbers for response identi󹪝er 7
No. Description
00 hex Illegal parameter number (access to a parameter that does not exist)
01 hex Parameter value cannot be changed (change request for a parameter value that cannot be
changed)
02 hex Lower or upper value limit exceeded (change request with a value outside the value limits)
03 hex Incorrect subindex (access to a subindex that does not exist)
04 hex No array (access with a subindex to non-indexed parameters)
05 hex Incorrect data type (change request with a value that does not match the data type of the
parameter)
06 hex Setting not permitted, only resetting (change request with a value not equal to 0 without
permission)
07 hex Descriptive element cannot be changed (change request to a descriptive element error
value that cannot be changed)
0B hex No master control (change request but with no master control, see also p0927)
0C hex Keyword missing
11 hex Request cannot be executed due to the operating state (access is not possible for tempo‐
rary reasons that are not speci󹪝ed)
14 hex Inadmissible value (change request with a value that is within the limits but which is illegal
for other permanent reasons, i.e. a parameter with de󹪝ned individual values)
65 hex Parameter number is currently deactivated (depending on the mode of the converter)
66 hex Channel width is insu󹪟cient (communication channel is too small for response)
68 hex Illegal parameter value (parameter can only assume certain values)
6A hex Request not included / task is not supported (the valid request identi󹪝cations can be found
in table "Request identi󹪝cations controller → converter")
6B hex No change access for a controller that is enabled. (The operating state of the converter
prevents a parameter change)
Advanced commissioning
8.6Drive control via PROFIBUS or PROFINET
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 219

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
