Siemens SINAMICS G120C DP User Manual

No. Description
86 hex Write access only for commissioning (p0010 = 15) (operating state of the converter pre‐
vents a parameter change)
87 hex Know-how protection active, access locked
C8hex Change request below the currently valid limit (change request to a value that lies within
the "absolute" limits, but is however below the currently valid lower limit)
C9hex Change request above the currently valid limit (example: a parameter value is too large for
the converter power)
CC hex Change request not permitted (change is not permitted as the access code is not available)
PNU (parameter number) and page index
Parameter number PNU Page index
0000 … 1999 0000 … 1999 0hex
2000…3999 0000 … 1999 80hex
6000 … 7999 0000 … 1999 90hex
8000 … 9999 0000 … 1999 20hex
10000 … 11999 0000 … 1999 A0hex
20000…21999 0000 … 1999 50hex
30000 … 31999 0000 … 1999 F0hex
60000 … 61999 0000 … 1999 74 hex
Subindex
For indexed parameters, the parameter index is located in subindex as hexadecimal value.
PWE: Parameter value or connector
Parameter values or connectors can be located in the PWE.
Table 8-26 Parameter value or connector
 PWE 1 PWE 2
Parameter value Bit 15…0 Bit 15…8 Bit 7…0
0 0 8-bit value
0 16-bit value
32-bit value
Connector Bit 15…0 Bit 15…10 Bit9…0
Number of the connector 3F hex The index or bit 󹪝eld
number of the connec‐
tor
Advanced commissioning
8.6Drive control via PROFIBUS or PROFINET
SINAMICS G120C Converters
220 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
