Converter Output reactor Output reactor as base
component
Frame size AA 0.55kW…2.2kW 6SL3210‑1KE11‑8...
6SL3210‑1KE12‑3...
6SL3210‑1KE13‑2...
6SL3210‑1KE14‑3...
6SL3210‑1KE15‑8...
6SL3202‑0AE16‑1CA0 6SE6400‑3TC00‑4AD2
1)
Frame size A 3.0kW…4.0 kW 6SL3210‑1KE17‑5..1
6SL3210‑1KE18‑8..1
6SL3202‑0AE18‑8CA0 ---
Frame size B 5.5kW…7.5kW 6SL3210‑1KE21‑3..1
6SL3210‑1KE21‑7..1
6SL3202‑0AE21‑8CA0 ---
Frame size C 11.0kW…18.5kW 6SL3210‑1KE22‑6..1
6SL3210‑1KE23‑2..1
6SL3210‑1KE23‑8..1
6SL3202‑0AE23‑8CA0 ---
Frame sizeD 22kW…37kW 6SL3210‑1KE24‑4..1
6SL3210‑1KE26‑0..1
6SL3210‑1KE27‑0..1
6SE6400-3TC07-5ED0 ---
45kW 6SL3210‑1KE28‑4..1 6SE6400‑3TC14‑5FD0 ---
Frame sizeE 55kW 6SL3210‑1KE31‑1..1
Frame sizeF 75kW…90kW 6SL3210‑1KE31‑4..1
6SL3210‑1KE31‑7..1
110kW 6SL3210‑1KE32‑1..1 6SL3000‑2BE32‑1AA0 ---
132kW 6SL3210‑1KE32‑4..1 6SL3000‑2BE32‑6AA0 ---
1)
with restrictions for G120C FSAA, 2.2kW. See below.
dv/dt 󹪝lter plus Voltage Peak Limiter
The "dv/dt 󹪝lter plus Voltage Peak Limiter" is intended for motors for which the voltage strength
is either unknown or is not adequate.
The dv/dt 󹪝lter plus Voltage Peak Limiter limits the voltage rate of rise and the voltage peaks
at the converter output.
Converter dv/dt 󹪝lter plus VPL
Frame sizeF 75kW…132kW 6SL3210‑1KE31‑4..1, 6SL3210‑1KE31‑7..1,
6SL3210‑1KE32‑1..1, 6SL3210‑1KE32‑4..1
6SL3000-2DE32-6AA0
Description
3.7Optional components
SINAMICS G120C Converters
36 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
