Braking resistor
The braking resistor allows the converter to actively brake loads with high moments of inertia.
Converter Braking resistor Braking resistor as base
component
Frame size AA 0.55kW…1.1kW 6SL3210‑1KE11‑8...
6SL3210‑1KE12‑3...
6SL3210‑1KE13‑2...
6SL3201‑0BE14‑3AA0 6SE6400‑4BD11‑0AA0
1)
1.5kW 6SL3210‑1KE14‑3...
2.2kW 6SL3210‑1KE15‑8... 6SL3201‑0BE21‑0AA0
Frame size A 3.0kW…4.0 kW 6SL3210‑1KE17‑5..1
6SL3210‑1KE18‑8..1
---
Frame size B 5.5kW…7.5kW 6SL3210‑1KE21‑3..1
6SL3210‑1KE21‑7..1
6SL3201‑0BE21‑8AA0 ---
Frame size C 11.0kW…18.5kW 6SL3210‑1KE22‑6..1
6SL3210‑1KE23‑2..1
6SL3210‑1KE23‑8..1
6SL3201‑0BE23‑8AA0 ---
Frame size D 22kW 6SL3210‑1KE24‑4..1 JJY:023422620001
2)
---
30kW…37kW 6SL3210‑1KE26‑0..1
6SL3210‑1KE27‑0..1
JJY:023424020001
2)
---
45kW 6SL3210‑1KE28‑4..1 JJY:023434020001
2)
---
Frame size E 55kW 6SL3210‑1KE31‑1..1
Frame size F 75kW…90kW 6SL3210‑1KE31‑4..1
6SL3210‑1KE31‑7..1
JJY:023454020001
2)
---
110kW…132kW 6SL3210‑1KE32‑1..1
6SL3210‑1KE32‑4..1
JJY:023464020001
2)
---
1)
with restrictions for G120C FSAA, 2.2kW. See below.
2)
Manufacturer: Heine Resistors GmbH
1)
restrictions for G120C FSAA, 2.2kW
Operation of the optional component is only permitted for operation of the converter with the
HO base load output = 1.5kW.
Supplementary optional components for the converter
In addition to the optional components o󹪜ered by SIEMENS, supplementary components are
also available from selected partners.
Further information is provided on the Internet:
Drive options partner (www.siemens.de/drives-options-partner)
Description
3.7Optional components
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 37

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
