Siemens SINAMICS G120C DP User Manual

Article No. without 󹪝lter
Article No. with 󹪝lter
6SL3210-1KE11-8U.1
6SL3210-1KE11-8A.1
6SL3210-1KE12-3U.1
6SL3210-1KE12-3A.1
6SL3210-1KE13-2U.1
6SL3210-1KE13-2A.1
HO base load power 0.37kW 0.55kW 0.75kW
HO base load input current 1.9A 2.5A 3.2A
HO base load output current 1.3A 1.7A 2.2A
Power loss with 󹪝lter 41W 45W 54W
Power loss without 󹪝lter 40W 44W 53W
Required cooling air 󹪞ow 5l/s 5l/s 5l/s
Weight with 󹪝lter 1.9kg 1.9kg 1.9kg
Weight without 󹪝lter 1.7kg 1.7kg 1.7kg
Table 11-4 Frame size A, 3-phase380…480VAC, +10%, -20%
Article No. without 󹪝lter
Article No. with 󹪝lter
6SL3210-1KE14-3U.1
6SL3210-1KE14-3A.1
6SL3210-1KE15-8U.1
6SL3210-1KE15-8A.1

Rated/LO base load power 1.5kW 2.2kW 
Rated/LO base load input current 5.5 A 7.4A 
Rated/LO base load output current 4.1 A 5.6A 
HO base load power 1.1kW 1.5kW 
HO base load input current 4.5A 6.0A 
HO base load output current 3.1A 4.1A 
Power loss with 󹪝lter 73W 91W 
Power loss without 󹪝lter 72W 89W 
Required cooling air 󹪞ow 5l/s 5l/s 
Weight with 󹪝lter 1.9kg 1.9kg 
Weight without 󹪝lter 1.7kg 1.7kg 
Table 11-5 Frame size A, 3-phase380…480VAC, +10%, -20%
Article No. without 󹪝lter
Article No. with 󹪝lter
6SL3210-1KE17-5U.1
6SL3210-1KE17-5A.1
6SL3210-1KE18-8U.1
6SL3210-1KE18-8A.1

Rated/LO base load power 3.0kW 4.0kW 
Rated/LO base load input current 9.5A 11.4 A 
Rated/LO base load output current 7.3A 8.8 A 
HO base load power 2.2kW 3.0kW 
HO base load input current 8.2A 10.6A 
HO base load output current 5.6A 7.3A 
Power loss with 󹪝lter 136W 146W 
Power loss without 󹪝lter 132W 141W 
Required cooling air 󹪞ow 5l/s 5l/s 
Weight with 󹪝lter 1.9kg 1.9kg 
Weight without 󹪝lter 1.7kg 1.7kg 
Technical data
11.5Technical data dependent on the power
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 427

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
