Siemens SINAMICS G120C DP User Manual

Table 11-6 Frame size B, 3-phase380…480VAC, +10%, -20%
Article No. without 󹪝lter
Article No. with 󹪝lter
6SL3210-1KE21-3U.1
6SL3210-1KE21-3A.1
6SL3210- 1KE21-7U.1
6SL3210-1KE21-7A.1

Rated/LO base load power 5.5kW 7.5kW 
Rated/LO base load input current 16.5A 21.5A 
Rated/LO base load output current 12.5A 16.5A 
HO base load power 4.0kW 5.5kW 
HO base load input current 12.8A 18.2A 
HO base load output current 8.8A 12.5A 
Power loss with 󹪝lter 177W 244W 
Power loss without 󹪝lter 174W 240W 
Required cooling air 󹪞ow 9l/s 9l/s 
Weight with 󹪝lter 2.5 kg 2.5 kg 
Weight without 󹪝lter 2.3kg 2.3kg 
Table 11-7 Frame size C, 3-phase380…480VAC, +10%, -20%
Article No. without 󹪝lter
Article No. with 󹪝lter
6SL3210-1KE22-6U.1
6SL3210-1KE22-6A.1
6SL3210-1KE23-2U.1
6SL3210-1KE23-2A.1
6SL3210-1KE23-8U.1
6SL3210-1KE23-8A.1
Rated/LO base load power 11kW 15kW 18.5kW
Rated/LO base load input current 33.0A 40.6A 48.2A
Rated/LO base load output current 25A 31A 37A
HO base load power 7.5kW 11kW 15kW
HO base load input current 24.1A 36.4A 45.2A
HO base load output current 16.5A 25A 31A
Power loss with 󹪝lter 349W 435W 503W
Power loss without 󹪝lter 344W 429W 493W
Required cooling air 󹪞ow 18l/s 18l/s 18l/s
Weight with 󹪝lter 4.7 kg 4.7 kg 4.7 kg
Weight without 󹪝lter 4.4kg 4.4kg 4.4kg
Table 11-8 Frame size D, 3AC380V…480V, +10%, -20%
Article No. without 󹪝lter
Article No. with 󹪝lter
6SL3210-1KE24-4U . 1
6SL3210-1KE24-4A . 1
6SL3210-1KE26-0U . 1
6SL3210-1KE26-0A . 1
6SL3210-1KE27-0U . 1
6SL3210-1KE27-0A . 1
Rated/LO base load power 22kW 30kW 37kW
Rated/LO base load input current 41A 53A 64A
Rated/LO base load output current 43A 58A 68A
HO base load power 18.5kW 22kW 30kW
HO base load input current 39A 44A 61A
HO base load output current 37A 43A 58A
Power loss with 󹪝lter 650W 933W 1.032kW
Technical data
11.5Technical data dependent on the power
SINAMICS G120C Converters
428 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
