Siemens SINAMICS G120C DP User Manual

Article No. without 󹪝lter
Article No. with 󹪝lter
6SL3210-1KE24-4U . 1
6SL3210-1KE24-4A . 1
6SL3210-1KE26-0U . 1
6SL3210-1KE26-0A . 1
6SL3210-1KE27-0U . 1
6SL3210-1KE27-0A . 1
Power loss without 󹪝lter 647W 927W 1.024kW
Required cooling air 󹪞ow 55l/s 55l/s 55l/s
Weight with 󹪝lter 19kg 19kg 20kg
Weight without 󹪝lter 17kg 17kg 18kg
Table 11-9 Frame size D, 3AC380V…480V, +10%, -20%
Article no. without 󹪝lter
Article no. with 󹪝lter
6SL3210-1KE28-4U . 1
6SL3210-1KE28-4A . 1
 
LO base load power 45kW  
LO base load input current 76A  
LO base load output current 82.5A  
HO base load power 37kW  
HO base load input current 69A  
HO base load output current 68A  
Power loss with 󹪝lter 1.304kW  
Power loss without 󹪝lter 1.291kW  
Required cooling air 󹪞ow 55l/s  
Weight with 󹪝lter 20kg  
Weight without 󹪝lter 18kg  
Table 11-10 Frame size E, 3AC380V…480V, +10%, -20%
Article no. without 󹪝lter
Article no. with 󹪝lter
6SL3210-1KE31-1U . 1
6SL3210-1KE31-1A . 1
 
LO base load power 55kW  
LO base load input current 96A  
LO base load output current 103A  
HO base load power 45kW  
HO base load input current 85A  
HO base load output current 83A  
Power loss with 󹪝lter 1.476kW  
Power loss without 󹪝lter 1.466kW  
Required cooling air 󹪞ow 83l/s  
Weight with 󹪝lter 29kg  
Weight without 󹪝lter 27kg  
Technical data
11.5Technical data dependent on the power
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 429

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
