Siemens SINAMICS G120C DP User Manual

Table 11-11 Frame size F, 3AC380V…480V
Article no. without 󹪝lter
Article no. with 󹪝lter
6SL3210-1KE31-4U . 1
6SL3210-1KE31-4A . 1
6SL3210-1KE31-7U . 1
6SL3210-1KE31-7A . 1
6SL3210-1KE32-1U . 1
6SL3210-1KE32-1A . 1
LO base load power 75kW 90kW 110kW
LO base load input current 134A 156A 187A
LO base load output current 136A 164A 201A
HO base load power 55kW 75kW 90kW
HO base load input current 112A 144A 169A
HO base load output current 103A 136A 164A
Power loss with 󹪝lter 1.474kW 1.885kW 2.245kW
Power loss without 󹪝lter 1.456kW 1.859kW 2.223kW
Required cooling air 󹪞ow 153l/s 153l/s 153l/s
Weight with 󹪝lter 64kg 64kg 66kg
Weight without 󹪝lter 59kg 59kg 62kg
Table 11-12 Frame size F, 3AC380V…480V
Article no. without 󹪝lter
Article no. with 󹪝lter
6SL3210-1KE32-4U . 1
6SL3210-1KE32-4A . 1
 
LO base load power 132kW  
LO base load input current 221A  
LO base load output current 237A  
HO base load power 110kW  
HO base load input current 207A  
HO base load output current 201A  
Power loss with 󹪝lter 2.803kW  
Power loss without 󹪝lter 2.772kW  
Required cooling air 󹪞ow 153l/s  
Weight with 󹪝lter 66kg  
Weight without 󹪝lter 62kg  
Technical data
11.5Technical data dependent on the power
SINAMICS G120C Converters
430 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
