Siemens SINAMICS G120C DP

Overview of the connections, FSD…FSF
/LQHVXSSO\0RWRU
/LQHVXSSO\0RWRU
%UDNLQJUHVLVWRU
%UDNLQJUHVLVWRU
/
/
/
/
/
/
8
9
:
8
9
:
)6')6(
)6)
5
5
)
5
5
)
Figure4-30 Connections for the line supply, motor and braking resistor
Connecting the line supply and motor, frame sizes FSD… FSE
Remove the lower connection covers.
You must re-attach the covers in order to re-establish
the touch protection of the converter after the cables
have been connected.
Installing
4.9Connect the line supply, motor and braking resistor
SINAMICS G120C Converters
72 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK
