Siemens SINUMERIK 802D sl Operation And Programming Manual

Programming
8-128
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
G17 * X/Y plane G group 6: Plane selection G17 .... ; Vertical axis on this
plane is the tool length
compensation axis
G500 * Settable work offset OFF G group 8: Settable work offset
ff
G54 * 1. settable zero offset
modally effective
G55 2nd settable work offset
G56 3rd settable work offset
G57 4th settable work offset
G58 5th settable work offset
G59 6th settable work offset
G53 Non-modal skipping of the settable work offset G group 9: Skip settable
work offset
G153 Non-modal skipping of the settable work offset
including base frame
work offset
non-modal
G60 * Exact stop G group 10: Approach behavior
ff
G64 Continuous-path control mode
modally effective
G9 Non-modal exact stop G group 11: Exact stop,
non-modal
G601 * Exact stop window, fine, with G60, G9 G group 12: Exact-stop window
dll ff i
G602 Exact stop window, coarse, with G60, G9
modally effective
G603 Exact stop at end of interpolation
G70 Inch dimension input G group 13: Inch / metr. dimension input
dll ff i
G71 * Metric dimension data input
modally effective
G700 Inch dimension data input; also for feedrate F
G710 Metric dimension data input; also for feedrate F
G90 * Absolute dimension data input G group 14: Absolute/incremental dimensions
ff
G91 Incremental dimension data input
modally effective
G94 * Feed F in mm/min G group 15: Feedrate/spindle
modally effective
CFC * Feedrate override with circle ON G group 16: Feedrate override
ff
CFTCP Feedrate override OFF
modally effective
