Siemens SINUMERIK 802D sl Operation And Programming Manual

AUTOMATIC Mode
5-57
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
If “Program test” (PRT) is selected, the output of setpoints to axes and spindles is disabled.
The set point display “simulates” the traversing movements.
If you select this softkey, all traversing movements are performed with the feedrate setpoint
specified via the “Dry run feed” setting data. Instead of the programmed motion commands,
the dry run feedrate will be effective.
If this function is active, the program execution is stopped at the blocks in which the miscel-
laneous function M01 is programmed.
Program blocks marked with a slash in front of the block number are skipped during the pro-
gram execution (e.g. “/N100”).
If this function is enabled, the part program blocks are executed separately as follows: Each
block is decoded separately and execution is interrupted after every block. “Single Block
fine” can only be selected in the RESET status.
The feedrate override switch also acts on the rapid traverse override.
Use this softkey to quit the screenform.
Use the block search function to go to the desired place in the program.
Forward block search with calculation to the block end point
During the block search, the same calculations are carried out as during normal program
operation, but the axes do not move.
Forward block search with calculation to the block end point
During the block search, the same calculations are carried out as during normal program
operation, but the axes do not move.
Block search without calculation
During the block search, no calculation is carried out.
The cursor is positioned on the interruption point.
The “Find” softkey provides the functions “Find line”, “Find text” etc.
Use this softkey to correct a faulty program passage. Any changes are stored immediately.
Opens the G functions window to display all G functions currently active.
The G functions window displays all G functions currently active whereby each G function is
assigned to a group and has a fixed position in the window.
Use the <PageUp> or <PageDown> keys to display further G functions.
Program
test
Dry run
feedrate
Conditional
stop
Skipping
Single
block fine
RTO
effective
Previous<<
Block
search
To
contour
To
end point
Without
calcul.
Interr.
Find
Program
correction
G
function
