Technical data
10
10.1 General information
Article number 7MH4138-6BA00-0CU0
General information
Product type designation Technology module TM SIWAREX WP351 HF
Firmware version V1.0
● FW update possible
Yes
usable BaseUnits BU type U0
Reliability
Mean Time Between Failure MTBF 60 years @T
A
= 40 °C (continuous operation)
Product function
I&M data Yes; I&M0 to I&M3
Engineering with
● STEP 7 TIA Portal can be configured/integrated as of ver‐
sion
Configurable as of V15 using HSP0281
● PROFIBUS as of GSD version/GSD revision
GSD revision 5
● PROFINET as of GSD version/GSD revision
GSDML V2.3
Supply voltage
Load voltage L+
● Rated value (DC)
24 V
● Permissible range, low limit, static (DC)
19.2 V
● Permissible range, high limit, static (DC)
28.8 V
● Permissible range, low limit, dynamic (DC)
18.5 V
● Permissible range, high limit, dynamic (DC)
30.2 V
● Polarity reversal protection
Yes
● Non-periodic overvoltages
35 V DC for 500 ms with a recovery time of 50 s
Input current
Current consumption, max. max. 140 mA @ 24 V DC + [DQ 3 x 0.5 A]
Power loss
Typical power loss 1.7 W
Address area
Assigned address area
● Inputs
32 bytes
● Outputs
32 bytes
Power supply from SIMATIC S7 backplane bus
Current consumption ET 200SP backplane bus max. 27 mA @ 3.5 V (SBK4)
Technology module TM SIWAREX WP351 HF
Operating Instructions, 01/2020, A5E47521010-AA 149
