6.8.3 Switch-on delay limit 3 (empty) (s) [delayTimeForEmptyLimit]
Switch-on delay limit 3 (empty) can be deliberately delayed by a delay time. This is helpful, for
example, if the weight is undershot at the moment of opening when the scale is being emptied,
which would cause Limit 3 to be fallen below already.
6.9 DR07 Interface parameters
6.9.1 Assignment DI.0, DI.1, DI.2, CI [functionDI0 to functionDI2] [functionCI]
Assign a command to each digital input (DI.0, DI.1, DI.2): → Commands (Page 112).
Use counter input CI optionally as a fourth digital input with its own reference potential.
Selection code
[functionDI0]
[functionDI1]
[functionDI2]
[functionCI]
Function
0 (default) The input operates as highspeed counter.
1 … 32759 Command codes 1 to 32759 according to section Commands
(Page 112). Triggered on transition from 0 → 1 at DI.x
Example for command code 1121 → selection code = 1121
32760 Transition weighing step 0
32761 Transition weighing step 1
32762 Transition weighing step 2
32763 Transition weighing step 3
32764 Transition weighing step 4
32765 Transition weighing step 5
32766 Transition weighing step 6
32767 Transition weighing step 7
32768 No function assigned
32769 … 65527 Command codes 1 to 32759 (+32768) according to section Commands
(Page 112). Triggered on transition from 1 → 0 at DI.x
Example for command 1121 → selection code = 1121 + 32768 = 33889
65528 Transition weighing step 0 (inverted)
65529 Transition weighing step 1 (inverted)
65530 Transition weighing step 2 (inverted)
65531 Transition weighing step 3 (inverted)
65532 Transition weighing step 4 (inverted)
65533 Transition weighing step 5 (inverted)
65534 Transition weighing step 6 (inverted)
65535 Transition weighing step 7 (inverted)
Parameter assignment/addressing
6.9 DR07 Interface parameters
Technology module TM SIWAREX WP351 HF
72 Operating Instructions, 01/2020, A5E47521010-AA
