Parameter assignment/addressing
6
6.1 Introduction
The following options are available for parameter assignment and addressing:
STEP 7 (TIA Portal) user program
Commissioning the electronic weighing system with TIA Portal (Page 38)
Calling the function block (FB) (Page 41)
Executing commands (Page 44)
Cyclic data exchange via "cyclicIoData" (Page 46)
Reading/writing data records (Page 48)
Web server
Calling the web server (Page 50)
Reading/writing data records (Page 51)
Parameter assignment
Modbus TCP/IP commissioning and parameter assignment
Communication via Modbus (Page 118)
Parameter table
In addition to the parameter descriptions, the parameter table (https://
support.industry.siemens.com/cs/ww/en/ps/7MH4138-6BA00-0CU0/dl) on the Internet
provides information on:
DR number
Parameter name
S7 name
Data type
Min. value
Max. value
Modbus address
Write protection
Access
Status information from DR30
Technology module TM SIWAREX WP351 HF
Operating Instructions, 01/2020, A5E47521010-AA 37
