6.17.11 Capture of weighings into statistics [statisticsData]
Defines, based on the tolerance evaluation, which dosing results are to be included in the
statistics calculation.
Selection code Meaning
0 (default) All dosings (with tolerance check) are included following "Dosing completed" in the
calculated statistics.
1 Dosings (with tolerance check) of "GOOD" class are included following "Dosing com‐
pleted" in the calculated statistics.
2 Dosings (with tolerance check) of "BAD" class are not included following "Dosing
completed" in the calculated statistics.
6.18 DR23 Material parameters
6.18.1 Parameter relation [parameterRelation]
The parameter defines how the specifications for the fine weight and trailing weight are to be
interpreted. The following options are available for selection:
Selection
code
Meaning
0 (default) Fine and trailing weights are interpreted as specified percentages of the set point (DS
20).
1 Fine and trailing weights are interpreted as absolute weights in the weight unit.
6.18.2 Fine weight [fineWeight]
Defines how much material is to be dosed only in the fine dosing phase. Depending on the
selected unit reference (DR23), the value must be interpreted as a percentage of the set point
(DR20) or as an absolute weight value.
Example:
Set point (DR20) = 100 kg
Selection code for parameter relation (DR 23) = 0
Fine value (DR 23) = 20
→ As a result of this setting, 20 kg (20% of 100 kg) is dosed with fine flow only.
Parameter assignment/addressing
6.18 DR23 Material parameters
Technology module TM SIWAREX WP351 HF
Operating Instructions, 01/2020, A5E47521010-AA 91
