Cut-off frequency low pass filter [cutOffFrequencyLowPassFilter]
Defines the limit frequency in Hz of the low pass filter in the range from 0.05 to 200 Hz.
Period of dosing filter [dosingFilterPeriod]
Defines the period of the dosing filter in seconds. The dosing filter has an additional effect on
the weight value during the coarse feed or fine feed. The period should be no longer than the
duration of the fine dosing phase.
6.5.25 Operating mode [scaleOperatingMode]
Defines the weighing mode of the scales.
The following weighing modes are available:
Selec‐
tion
code
0 NAWI - Non-automatic weighing instrument - Filling (Page 53)
1 NAWI - Non-automatic weighing instrument - Emptying (Page 54)
10 GFI - Gravimetric filling instrument (Page 55) - Filling
11 GFI - Gravimetric filling instrument (Page 55) - Emptying
20 CWI - Catchweighing instrument/ CW - Automatic check weigher - Filling (Page 55)
21 CWI - Catchweighing instrument/ CW - Automatic check weigher - Emptying (Page 56)
30 DTI Discontinuous totalizing automatic weighing instrument (Page 57) - Mode A
31 DTI Discontinuous totalizing automatic weighing instrument (Page 57) - Mode B
40 CW - Automatic check weigher (Page 58)
6.5.26 Totalization scale interval dt [TotalizationScaleIntervalDt]
This parameter defines the resolution of the totals 1 in DR30. In DTI mode, this parameter
represents the totalization scale interval dt of the legal-for-trade total.
6.5.27 Minimum totalized load [minimumTotalizedLoad]
The parameter defines the minimum totalized load in THW mode.
6.5.28 SecureDisplay interface [legalDisplayInterface]
For legal-for-trade operation, the "SecureDisplay" software is used to display the legal-for-trade
weight value. The parameter defines whether "SecureDisplay" communicates directly via the
Ethernet port of the electronic weighing system or via the Ethernet port of the SIMATIC
controller.
Parameter assignment/addressing
6.5 DR03 Calibration parameters
Technology module TM SIWAREX WP351 HF
Operating Instructions, 01/2020, A5E47521010-AA 69
