6.9.12 Modbus TCP Unit Identifier, port, SWAP options
The following options are available for the Modbus TCP/IP interface:
Selection code
[modbusUnitIdentifier1]
Function
-1 (default) Unit Identifier is not evaluated
Modbus TCP port connection [modbusPort]
Defines the port for the Modbus connections.
6.9.13 Byte/Word swap options [byteSwap16Bit] [byteSwap32Bit] [wordSwap32Bit]
Defines the format used for transfer over the Ethernet interface (MODBUS TCP IP).
6.9.14 RS485 protocol
Configures the serial interface RS485.
Selection code Protocol
0 (default) Deactivated
6.9.15 I/O process values 1 to 4 [ioProcessValue1 to ioProcessValue4]
You can transfer up to four selectable I/O process values from the electronic weighing system
to the CPU cyclically via the I/O. The following I/O process values can be selected:
Table 6-2 Selection table for I/O process values 1, 2, 3 and 4
I/O process value Selection code
No element is selected 0
Gross process weight 1 1
Net process weight 1 2
Tare process weight 3
Net weight 4
Gross / net weight x10 (legal-for-trade) 5
Gross weight 6
Tare weight (legal-for-trade) 7
Gross process weight 2 8
Net process weight 2 9
Unfiltered digit value 10
Digits filtered by F1 11
Digits filtered by F2 12
Parameter assignment/addressing
6.9 DR07 Interface parameters
Technology module TM SIWAREX WP351 HF
76 Operating Instructions, 01/2020, A5E47521010-AA
