6.9.2 Filtering DI.0, DI.1, DI.2 and CI
Specify the following values for filtering the digital inputs and the counter input:
Selection codes
Filter DI.0 [filterDI0]
Filter DI.1 [filterDI1]
Filter DI.2 [filterDI2]
Filter CI [filterCI]
Function
0 (default) No filtering
1 … 2500 [0.1 ms] Filtering from 0.1 to 250 ms
6.9.3 Assignment DQ.0, DQ.1, DQ.2
Selection code
[functionDQ0]
[functionDQ1]
[functionDQ2]
Function
0 … 79 Corresponding bit of the scale status (see DR30)
80 Controlled via S7 I/O
81 Controlled via data record 18
100 … 179 Corresponding inverted bit of the scale status (see DR30)
255 (default) Output deactivated
1000 … 1063 Corresponding operating error (see DR32)
1100 … 1163 Corresponding inverted operating error (see DR32)
2000 … 2063 Corresponding technology message (see DR32)
2100 … 2163 Corresponding inverted technology message (see DR32)
3000 … 3063 Corresponding data/operating error (see DR32)
3100 … 3163 Corresponding inverted data/operating error (see DR32)
See also
Commands (Page 111)
6.9.4 Reaction to CPU stop / failure [behaviourOnCPUStopOrFailure]
Selection code Function
0 (default) Active dosing is stopped
1 Active dosing is continued
Parameter assignment/addressing
6.9 DR07 Interface parameters
Technology module TM SIWAREX WP351 HF
Operating Instructions, 01/2020, A5E47521010-AA 73
