Functional Description
AG06 Date: 07.02.2018 Art. No. 85674 Mod. status 055/18 Page 12 of 114
4.2 Manual control (stand-alone operation)
4.2.1 Start inching mode 2
After applying supply voltage, the actuator will be on the uppermost level of the menu
structure (default/delivery state). Positioning mode is active.
Pressing the key starts left-hand motion (inching operation 2).
Pressing the key starts right-hand motion (inching operation 2).
Releasing the respective key stops travel movement.
Pressing the key starts the parameterization/programming mode.
4.2.2 Specifying the set point and starting the travel order
4.2.2.1 Example: Starting positioning order to position 500
Preconditions:
 The display is at the uppermost level of the menu structure (basic state).
 Operating mode: Positioning mode
 Key functions: enabled


Initial state: normal display
First press the key, then the key and hold down together.


The key enable time is counted down.


After expiry of the key enable time, the input field is released.
The first decimal place is active.
Press the key twice to change the active decimal place.


The third decimal place is active.
Press the key 5 times.


Value 500 will be displayed.
Confirm by pressing the key to start positioning.
4.2.2.2 Example: Starting positioning order to position -500
Preconditions:
 The display is at the uppermost level of the menu structure (basic state).
 Operating mode: Positioning mode
 Key functions: enabled
For negative values to be entered, set first the value and only afterwards
the arithmetical sign. The value 0 cannot be entered.
