Siko AG06 - Manufacturer Device Name; Manufacturer Software Version

Communication via CAN bus
AG06 Date: 07.02.2018 Art. No. 85674 Mod. status 055/18 Page 66 of 114
Format description:
Bit 31 - 30
not used
Bit 29
0 = 11-bit identifier (CAN 2.0A)
1 = 29-bit identifier (CAN 2.0B)
Bit 28 - 11
if bit 29=1, Bit 28 ... 11 des 29-bit identifier
Bit 10 - 0
bit 10 ... 0 of the identifier
9.13.2.6 1008
h
: Manufacturer Device Name
Object 1008
h
indicates the device name.
Sub-index
00
h
Description
Device name in ASCII characters
Access
const
PDO mapping
no
Data type
Visible String
Default
no
EEPROM
no
Format description (example):
Bit 7 - 0
41
h
= ' A ' (ASCII character, ISO 8859)
Bit 15 - 8
47
h
= ' G ' (ASCII character, ISO 8859)
Bit 23 - 16
30
h
= ' 0 ' (ASCII character, ISO 8859)
Bit 31 - 24
36
h
= ' 6 ' (ASCII character, ISO 8859)
Device name = AG06
9.13.2.7 100A
h
: Manufacturer Software Version
Object 100A
h
indicates the software version of the controller firmware.
Sub-index
00
h
Description
Software version as ASCII characters
Access
const
PDO mapping
no
Data type
Visible String
Default
no
EEPROM
no
Format description (example):
Bit 7 - 0
31
h
= ' 1 ' (ASCII character, ISO 8859)
Bit 15 - 8
2E
h
= ' . ' (ASCII character, ISO 8859)
Bit 23 - 16
30
h
= ' 0 ' (ASCII character, ISO 8859)
Bit 31 - 24
30
h
= ' 0 ' (ASCII character, ISO 8859)
Software version = V 1.00
