Siko AG06 - Heartbeat Protocol

Communication via CAN bus
AG06 Date: 07.02.2018 Art. No. 85674 Mod. status 055/18 Page 48 of 114
Error Code
Meaning
Byte 0
(Highbyte)
Byte 1
(Lowbyte)
FF
08
h
Manufacturer specific
Define Mismatch
The state machine was set to the 'Fault' state.
Fault is deposited in the fault buffer.
FF
09
h
Manufacturer specific
Battery Undervoltage
The state machine was set to the 'Fault' state.
Fault is deposited in the fault buffer.
FF
0A
h
Manufacturer specific
Unknown Bustype
The state machine was set to the 'Fault' state.
Fault is deposited in the fault buffer.
FF
0B
h
Manufacturer specific
Queue 1 overrun
The state machine was set to the 'Fault' state.
Fault is deposited in the fault buffer.
FF
0C
h
Manufacturer specific
Queue 2 overrun
The state machine was set to the 'Fault' state.
Fault is deposited in the fault buffer.
FF
0D
h
Manufacturer specific
Question Answer
The state machine was set to the 'Fault' state.
Fault is deposited in the fault buffer.
FF
0E
h
Manufacturer specific
Checksum EEPROM
The state machine was set to the 'Fault' state.
Fault is deposited in the fault buffer.
FF
0F
h
Manufacturer specific
Queue 3 Overrun
The state machine was set to the 'Fault' state.
Fault is deposited in the fault buffer.
FF
10
h
Manufacturer specific
Queue 4 Overrun
The state machine was set to the 'Fault' state.
Fault is deposited in the fault buffer.
Table 27: Error Code
9.3.10 Heartbeat protocol
The master monitors the state of the actuator via heartbeat protocol. While doing this, the
actuator sends cyclically its NMT status.
The actuator sends the heartbeat telegram independently, without request via RTR frame. The
actuator is a heartbeat producer, it does not receive nor process heartbeat protocols.
