Siko AG06 - Actuator; Limiting Values

Functional Description
AG06 Date: 07.02.2018 Art. No. 85674 Mod. status 055/18 Page 17 of 114
4.3.1.3 Actuator
Menu


Sub-menu


Parameter
Description

Acceleration in the positioning mode
Value range: 1 – 100
(see chapter 8: Parameter description  Parameter no. 4)

Maximum speed in the positioning mode
Gear 188:1  value range: 1 - 30
Gear 368:1  value range: 1 - 15
(see chapter 8: Parameter description  Parameter no. 5)

Acceleration in rotational speed mode
Value range: 1 - 100
(see chapter 8: Parameter description  Parameter no. 6)

Acceleration in inching mode 1/2
Value range: 1 - 100
(see chapter 8: Parameter description  Parameter no. 8)

Maximum speed in inching mode 1/2
Gear 188:1  value range: 1 - 30
Gear 368:1  value range: 1 - 15
(see chapter 8: Parameter description  Parameter no. 9)

Numerator gear ratio
Value range: 1 - 10000
(see chapter 8: Parameter description  Parameter no. 11)

Denominator gear ratio
Value range: 1 - 10000
(see chapter 8: Parameter description  Parameter no. 12)
Table 5: Actuator menu
4.3.1.4 Limiting values
Menu


Sub-menu


Parameter
Description

Limit 1
Value range: -19999 … 99999
(see chapter 8: Parameter description  Parameter no. 15)

Limit 2
Value range: -19999 … 99999
(see chapter 8: Parameter description  Parameter no. 16)
