Parameter description
AG06 Date: 07.02.2018 Art. No. 85674 Mod. status 055/18 Page 26 of 114
No.
Name
Selection
/ value
Default
Description
S
C
5
v - pos
see
Description
column
10
Maximum speed in the positioning mode:
values in rpm
Gear 188:1  1 – 30 rpm
Gear 368:1  1 – 15 rpm
S
2
6
a - rot
1 - 100
50
Acceleration in rotational speed mode:
values in %
100 % correspond to:
Gear 188:1  1.06 rps
2
Gear 368:1  0.54 rps
2
S
2
7
reserved
8
a - inch
1 - 100
50
Acceleration in inching mode 1/2:
values in %
100 % correspond to:
Gear 188:1  1.06 rps
2
Gear 368:1  0.54 rps
2
S
2
9
v - inch
see
Description
column
10
Maximum speed in inching mode 1/2:
values in rpm
Gear 188:1  1 – 30 rpm
Gear 368:1  1 – 15 rpm
S
2
10
Pos window
0 - 1000
10
Operating mode: Positioning mode:
Positioning window
If the actual position of the actuator is
within the programmed set point ± this
window, this is signalled by setting bit 3 in
the status word of the actuator.
Spindle pitch = 0: Values refer to increments
Spindle pitch > 0: Values refer to travel
distance in 1/100 mm
Operating mode: Speed mode:
If the actual rotational speed is within the
target rotational speed ± this window, this
is signalled by setting bit 3 in the system
status word of the actuator.
S
1
11
ü -
numerator
1 - 10000
1
Numerator gear ratio:
a gear factor can be programmed here when
a gear is used.
S
1
12
ü -
denomina-
tor
1 - 10000
1
Denominator gear ratio:
a gear factor can be programmed here when
a gear is used.
S
1
