9.13.2.19 1600
h
: 1
st
Receive PDO Mapping Parameter
Object 1600
h
determines the objects that are mapped on the first Receive PDO (RPDO1).
Sub-index
00
h
Description
Number of mapped application objects in RPDO 1
Access
read-only
PDO mapping
no
Data type
Unsigned8
Default
1
EEPROM
no
Sub-index
01
h
Description
first object mapped
Access
read-only
PDO mapping
no
Data type
Unsigned32
Default
60400010
h
EEPROM
no
Format description sub-index 01
h
:
Bit 31 - 16
Index 16 bits
Bit 15 - 8
Sub-index 8 bits
Bit 7 - 0
8 bits object length
Data description:
The object cannot be changed (static mapping).
Mapped objects:
 Object 6040
h
(control word) in bytes 0 and 1.
9.13.2.20 1601
h
: 2
nd
Receive PDO Mapping Parameter
Object 1601
h
was implemented for compatibility reasons only and has no function.
Sub-index
00
h
Description
Number of mapped application objects in RPDO 2
Access
read-only
PDO mapping
no
Data type
Unsigned8
Default
0
EEPROM
no
