AG06 Date: 07.02.2018 Art. No. 85674 Mod. status 055/18 Page 22 of 114
4.3.3 Error memory
Menu


Parameter
Description


Number of errors in the error memory
(see chapter 8: Parameter description  Parameter no. 61)

xxxxx
Error 1
(see chapter 8: Parameter description  Parameter no. 62)

xxxxx
Error 2
(see chapter 8: Parameter description  Parameter no. 63)

xxxxx
Error 3
(see chapter 8: Parameter description  Parameter no. 64)

xxxxx
Error 4
(see chapter 8: Parameter description  Parameter no. 65)

xxxxx
Error 5
(see chapter 8: Parameter description  Parameter no. 66)

xxxxx
Error 6
(see chapter 8: Parameter description  Parameter no. 67)

xxxxx
Error 7
(see chapter 8: Parameter description  Parameter no. 68)

xxxxx
Error 8
(see chapter 8: Parameter description  Parameter no. 69)

xxxxx
Error 9
(see chapter 8: Parameter description  Parameter no. 70)

xxxxx
Error 10
(see chapter 8: Parameter description  Parameter no. 71)
Table 11: Error memory menu
xxxxx = Plain text display of error codes (see chapter 7.2.1: Error codes)
5 Calibration
Since the measuring system is an absolute system, calibration is necessary only once with
commissioning. With calibration, the calibration value is adopted for calculation of the
position value. The following equation is applied in case of calibration:
Position value = 0 + calibration value + offset value
Writing a value onto the calibration value parameter (see chapter 8: Parameter description 
Parameter no.14) will result in the adoption of such value as the absolute position for the
actuator.
Offset value (see chapter 8: Parameter description  Parameter no. 32)
