Parameter description
AG06 Date: 07.02.2018 Art. No. 85674 Mod. status 055/18 Page 27 of 114
No.
Name
Selection
/ value
Default
Description
S
C
13
Spindle
pitch
0 -
1000000
0
Spindle pitch:
Spindle pitch parameter = 0:
Position value is output in increments (720
increments per revolution of the driving
shaft).
Spindle pitch parameter > 0:
(when operating the actuator on a spindle)
The position value is output as travelling
distance in 1/100 mm , not in increments.
Input of target position is now in 1/100 mm
as well.
e. g. spindle with a pitch of 2 mm 
Spindle pitch parameter = 200.
S
1
14
Calibration
value
-999999 to
999999
0
Calibration value:
Changes in the calibration value will be
directly adopted for the calculation of the
position value.
Position value = 0 + calibration value +
offset value
S
1
15
Limit 1
-9999999
to 9999999
99999
Operating mode: Positioning mode: Limit
1
Spindle pitch = 0: Values refer to increments
Spindle pitch > 0: Values refer to travelling
distance in 1/100 mm
If actuator's position is beyond the range
defined by limit 1 and limit 2 (travel
range), travelling will only be possible in
inching mode in the direction of the travel
range.
Notice! Limit monitoring is deactivated if
'limit 1' is equal 'limit 2'. Please note that
there is a jump of the actual position if the
resolution of the absolute encoder is
exceeded!
Operating mode: Speed mode:
irrelevant
S
1
