Siko AG06 - Example: Write Parameter

Communication via CAN bus
AG06 Date: 07.02.2018 Art. No. 85674 Mod. status 055/18 Page 45 of 114
Identifier = 1536 + 5 = 1541 = 605
h
Command code = Read request (= request of a parameter from the actuator) = 40
h
Index = 607C
h
The index of the parameter calibration value was taken from the directory of objects (chapter
9.13.2: Description of objects).
Sub-index= 0
The current calibration value is 2500 = 9C4
h
.
Telegram from the master to the actuator:
Identifier
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
605
h
40
h
7C
h
60
h
00
h
00
h
00
h
00
h
00
h
Response of the actuator:
Identifier
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
585
h
42
h
7C
h
60
h
00
h
C4
h
09
h
00
h
00
h
Command code = Read Response = 42
h
Calculation of the identifier:
Identifier of the parameter channel from the actuator to the master = 580
h
+ device address
580
h
= 1408
dec
Identifier = 1408 + 5 = 1413 = 585
h
9.3.8.2 Example: Write parameter
For the actuator with device address 5 the limit 1 is to be set to 2000000!
Calculation of the identifier:
Identifier of the parameter channel to the actuator = 600
h
+ device address
600
h
= 1536
dec
Identifier = 1536 + 5 = 1541 = 605
h
Command code = Write request (send parameter to the actuator) = 23
h
Index = 607D
h
Sub-index = 2
The index and the sub-index of the parameter 'limit 1' were taken from the directory of
objects (chapter 9.13.2: Description of objects).
2000000 = 1E8480
h
Telegram from the master to the actuator:
Identifier
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
605
h
23
h
7D
h
60
h
02
h
80
h
84
h
1E
h
00
h
Response of the actuator in the case of error-free execution:
Identifier
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
585
h
60
h
7D
h
60
h
02
h
00
h
00
h
00
h
00
