User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
UN3 UN5
thermocouple inputs
RTD inputs
resistance input
K, S, J, T, N, R, E, L(GOST), B, C
Pt100, Pt'100, Pt'50, Pt500,
Pt'500, Pt1000, Cu50, Cu'50,
Cu100, Cu'100, Ni100, Ni500,
Ni1000
0÷300Ω
0÷3000Ω
K, S, J, T, N, R, E, L(GOST), B, C
Pt100, Pt'100, Pt'50, Pt500,
Pt'500, Pt1000, Cu50, Cu'50,
Cu100, Cu'100, Ni100, Ni500,
Ni1000
0÷300Ω
0÷3000Ω
Connection method in
RTD
mode
2, 3 and 4 wire
(switched manually)
2, 3 and 4 wire
(switched manually)
Input impedance
current inputs
voltage inputs
thermocouple inputs
RTD inputs
<65Ω (typ. 30Ω)
>100kΩ (while maintaining correct
polarization)
≥6MΩ
≈4kΩ
<65Ω (typ. 30Ω)
>100kΩ (while maintaining correct
polarization)
≥6MΩ
≈4kΩ
Precision
current inputs
voltage inputs
thermocouple inputs
RTD inputs
0.1% @ 25˚C for all ranges
0.1% @ 25˚C for ranges:
0÷5V, 1÷5V, 0÷10V, -10÷100mV,
0÷600mV
0.15% @ 25˚C for range:
-10÷25mV
0.15% @ 25˚C for range 30mV
0.1% @ 25˚C for range 120mV
0.1% @ 25˚C for ranges:
0÷300Ω, 0÷3000Ω
0.1% @ 25˚C for all ranges
0.1% @ 25˚C for ranges:
0÷5V, 1÷5V, 0÷10V, -10÷100mV,
0÷600mV
0.15% @ 25˚C for range:
-10÷25mV
0.15% @ 25˚C for range 30mV
0.1% @ 25˚C for range 120mV
0.1% @ 25˚C for ranges:
0÷300Ω, 0÷3000Ω
Temperature stability 50 ppm/˚C 50 ppm/˚C
Sampling period in mode:
current inputs:
voltage inputs:
thermocouple inputs:
RTD inputs:
resistance inputs:
535ms
535ms
535ms
1410ms
1410ms
535ms
535ms
535ms
1410ms
1410ms
Isolation strength 1 min. @ 500V AC 1 min. @ 500V AC
Weight 74 g 77 g
Tab. 8.13 Technical data for the UN3 and UN5 modules
