User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Fig. 8.26. Internal structure of the SSR output module (24 outputs)
271
F
100mA
Interface
Driver
OUT 1-8
F
500mA
Vcc 1
OUT 1-8
GND
Main board
10V
F
100mA
F
500mA
Vcc 2
Driver
OUT 9-16
OUT 9-16
GND
F
100mA
F
500mA
Vcc 3
Driver
OUT 17-24
OUT 17-24
GND
