1. Remove the front door.
2. Remove the image cartridge.
3. Unlatch the left bushing latch on transfer roller and pull it up.
4. In the same manner, unlatch the right bushing latch and lift it up to remove the transfer roller.
When disassemble, be careful not to touch the transfer roll.
