Sindoh M401 - Pick up ASSY Components; Tray ASSY Components

Pick Up ASSY Components
Pick up ASSY is an ASSY feeding the documents set on tray by user to inside of ADF. Pick up ASSY can be
divided with pick roller, feed roller and mounting pick up holder along with pick up shaft operating them.
Life Cycle of Pick up ASSY is identical with ADF’s life Cycle. Pick up ASSY has mount and removal
functions to remove paper jam.
Tray ASSY Components
Pick Up Holder
Feed Roller
Pick Up Shaft
Feed Roller
Side Fence
Pinion Gear
Isolation Pad ASSY
Rear Fence
Front Fence
Document Tray
