Sindoh M401 - Fax SETUP; Fax Setting; Modem Setting

4. Use arrow keys to set the signal to test and press Select key. When the signal is selected, output
signal is sent and continued until stop key is pressed.
5. Use measuring instrument to inspect and press Stop key.
6. To exit, press Return.
Fax SETUP
Fax Setting
1. Select Fax Test from diagnosis mode.
2. Select Fax Setting
3. Use arrow keys to select a menu to test and press Select key. The categories that can be tested
from Fax Setting are the followings.
1) Tx Speed
(1) V.34
(2) V.17
(3) V.29
(4) V.27
2) Rx Speed
(1) V.34
(2) V.17
(3) V.29
(4) V.27
3) Coding Option
(1) MH
(2) MH/MR
(3) MH/MR/MMR
(4) MH/MR/MMR/JBIG
4) Print T30 Log
5) Detect EOLs: Configuration range 0~6. default 3
4. Press OK to save settings.
5. To exit, press Return.
Modem Setting
This function is used as to change Modem configurations.
